Built-in high performance Hisilicon chipset, coded with H.264 standard, high compression rate and image quality
Video input: 4 channels AHD video input，total resources 4*1080P@10fps
Video output: 1channel VGA video output，1channel CVBS output
Audio input: 4 channels(include 1 channel MIC input)
Audio input: 1 channel audio output
SIM/ESIM optional, IRNSS optional
POWER
Wide voltage design: support true DC 8-36V vehicle power input, the front end of the system is designed as a buck-boost power supply design, which is not affected by vehicle power supply fluctuations, ensuring a stable output of 12V@7A total load of the system, and supporting a distance of 30 meters between the host and the camera.
Automotive-grade power supply design: The high-power power supply chip adopts an external MOS switching design, which has the advantage of reducing overshoot and heat dissipation.
Multiple protection design of vehicle power supply.
EMC, EMI Design.
Anti-power failure function.
Chip-level protection and independent protection.
Anti back-flow function.
DATA STORAGE
Special file management system to encrypt and protect the data
Proprietary technology to detect the bad track of the hard drive which can make sure the continuity of video and long service life of the hard driveŸ
Built-in ultra capacitor, avoid data loss and SD card damage caused by sudden outage
Support 2.5 inch HDD/SSD, maximum 2TB
Support SD card storage, maximum 256GB
Support hard disk heating
TRANSMISSION INTERFACE
Support 3G/4G transmission, EVDO/TD-SCDMA/WCDMA/TDD-LTE/FDD-LTE
Support GPS/BD optional, high sensitivity, fast positioning
Support WiFi, 802.11b/g/n, 2.4GHz
|
Item |
Device parameter |
Performance indicator |
|
System |
Operating system |
Linux |
|
Operating language |
Chinese/English |
|
|
Control mode |
Mouse operation, Remote control |
|
|
Operation interface |
Graphical menu operation interface(OSD menu) |
|
|
Password security |
User password and administrator password two-level management |
|
|
Video
|
Input |
4-CH AHD |
|
Output |
1-CH VGA, 1-CH CVBS |
|
|
Preview |
1-CH, 4-CH preview |
|
|
Total resource |
4*1080P@10fps |
|
|
Audio |
Input |
4-CH (Includes 1-CH MIC) |
|
Output |
1-CH |
|
|
Recording method |
Simultaneous recording of sound and video |
|
|
Network |
3G/4G |
EVDO/TD-SCDMA/WCDMA/TDD-LTE/FDD-LTE(Optional) Support replacement of modules in different regions and bands |
|
WIFI |
Supports 802.11b/g/n |
|
|
IPC interface |
100Mbps wired network |
|
|
Storage |
HDD/SSD |
1 x2.5"SATA HDD or SSD(Hard disk heating is optional) |
|
SD |
Supports 1-CH SD, doesn't support plug and play(at maximum 256G) |
|
|
Positioning |
GPS/BD |
The geographic coordinates, speed, etc. can be written into the encoded stream, and the time is synchronized |
|
Sensor |
G-Sensor |
Built-in |
|
Interface |
USB |
1 x USB2.0(Type A), for firmware upgrade and mouse connection |
|
SIM |
1 x SIM card slot |
|
|
Serial port |
2 x RS232, 1 x RS485 |
|
|
Alarm input, output |
4-CH Sensor in, 2-CH Sensor out |
|
|
Intercom |
1xMIC interface |
|
|
Remote control |
Supports infrared remote control |
|
|
5V Output |
5V@500mA(RS232&RS485 interfaces) |
|
|
12V Output |
12V@500mA(SENSOR interface) |
|
|
GPS interface |
Built-in GPS antenna interface with SMA connector for connecting GPS antenna |
|
|
4G interface |
Built-in SMA connector for connecting 4G antenna |
|
|
WIFI inteface |
For connecting WIFI antenna |
|
|
Power |
Power input |
DC: 8V～36V |
|
Maximum typical power consumption |
48W |
|
|
Standby consumption |
≈0W |
|
|
Environment |
Working temperature |
-40℃~+70℃(With heating, no hard disk) |
|
Working humidity |
8%-95%(No Condense) |
